Air-Cooled Diesel Engine Generator 16Kw (20Kva) V-twin 4-cycle With Free ATS

SKU KK20000-ATS

R97 500.00

Sold out

Price incl. SA Vat (15%) R12 717.39

OPTION

220V Single Phase

Sold out

Product Details


Generator	Model	KK20000S	KK20000S3
	Frequency	50Hz	50Hz
	Rated Power	18.7KVA/15KW	18.7KVA/15KW
	Max. Power	16KW/20KVA	16KW/20KVA
	Voltage(A.C)	220V	380V
	Phase	Single phase	3 phase
	Power factor cosφ	1	0.8
	Insulation	H
Engine	Type	V-twin、4-cycle、air-cooled diesel engine
	Model	CD2V95F
	Bore×stroke	2V-95*88mm
	Displacement	1.247L
	Compression ratio	19:1
	Engine speed	3000rpm
	Rated output	19kw
	Combustion system	Direct injection
	Starting system	Electric starter
	Lube oil capacity	3.8L
	Lubrication oil	CD grade or higher（SAE10W/30、SAE15W/40）
	Fuel oil	diesel fuel
Unit	Fuel tank capacity	26L
	Fuel consumption	≤5.5L/h
	Noise level at 7m dB(A)	73~75
	Product dimensions	1300650760mm
	Weight	320kg
